Technical parameters
Replacement of open pipe size Ø (mm)
10
Purging Force (N)
20.0
Air Consumption (Nm³/h)
114
Sound Level (dB(A))
90
Air nozzle technology
Slots
Material (Air Nozzle)
Zn
connect
G 1/2″
Connection
Internal (Threaded)
Weight (g)
275
Maximum Operating Temperature (°C)
70
Maximum Operating Pressure (MPa)
1.0
Benefits of replacing open end tubes.
Replacement of open pipe size Ø (mm)
10
Sound level levels decrease
22 [dB(A)]
78%
Noise reduction and energy saving
71 [Nm³/h]
38%
Material description: Zn ZP0410 EN 1284, EN 1.0718 Fzb
Purging properties at different pressures
Pressure (kPa)
200
400
600
800
1000
Purging Force (N)
8.4
15.6
24.0
30.6
37.8
Air Consumption (Nm³/h)
55.8
91.8
136.8
178.8
220.8
Sound Level (dB(A))
82.0
87.8
92.0
95.9
98.5
