echnical parameters
Replacement of open pipe size Ø (mm)
6
Purging Force (N)
5.5
Air Consumption (Nm³/h)
28
Sound Level (dB(A))
78
Air nozzle technology
Laval
Material (Air Nozzle)
Zn
connect
G 1/4″
Connection
External (Threaded)
Weight (g)
116
Maximum Operating Temperature (°C)
70
Maximum Operating Pressure (MPa)
1.0
Benefits of replacing open end tubes.
Replacement of open pipe size Ø (mm)
6
Sound level levels are reduced
24 [dB(A)]
81%
Noise reduction and energy saving
39 [Nm³/h]
58%
Material Description: Zn ZP0410 EN 12844
Purging properties at different pressures
Pressure (kPa)
200
400
600
800
1000
Purging Force (N)
2.4
4.6
6.8
8.9
11.1
Air Consumption (Nm³/h)
13.3
23.2
33.2
43.2
53.1
Sound Level (dB(A))
69.9
76.0
79.0
84.1
86.4
