Replacement of open pipe size Ø (mm)
12
Purging Force (N)
22.5
Air Consumption (Nm³/h)
120
Sound Level (dB(A))
96
Air nozzle technology
Dorawal
Material (Air Nozzle)
1.4404 (316L)
connect
G 1/2″
Connection
Internal (Threaded)
Weight (g)
47
Maximum Operating Temperature (°C)
400
Maximum Operating Pressure (MPa)
1.0
Benefits of replacing open end tubes.
Replacement of open pipe size Ø (mm)
12
Sound level levels decrease
20 [dB(A)]
75%
Noise reduction and energy saving
146 [Nm³/h]
55%
Material Description: EN 1.4404
Purging properties at different pressures
Pressure (kPa)
200
400
600
800
1000
Purging Force (N)
8.7
17.9
27.0
36.2
45.3
Air Consumption (Nm³/h)
64.0
101.0
142.0
180.0
219.0
Sound Level (dB(A))
92.1
94.4
95.9
96.8
97.2
