SUS304
Available diameter : ø3.0~ø25.4
Details of contents : Ni 18.0～10.5, Cr 18.0～20.0, Mn 2.0MAX, Fe Bal。
Proper environment : Air heating，In contact with heated objects。
Limit service temperature(UL) : According to use environment。
Features
The lead wires (terminals) are concentrated on a single side for easy installation and wiring in small spaces 。
May also be used for defrosting in long-size and small-capacity operations。
Large capacity in small size. Yields high temperature in small spaces。
Improves the temperature uniformity of metallic blocks by changing the winding pitches of the heating wires。
Application examples
Maintaining mold temperature、preventing freezing、ice makers、and medical equipment。
etc。
Precautions
These heaters are available in length from 30 mm to 1500 mm。
Use them in water or inserting metallic molds in contact with the objects to be heated。
Reduce the surface temperature when using them in air。
SUS321
Available diameter : ø3.0~ø25.4
Details of contents : Ni 9.0～13.0, Cr 17.0～19.0, Ti 5*C%MAX, Mn 2.0MAX, Fe Bal。
Proper environment : Air heating。
Limit service temperature(UL) : Depends on the use environment。
Features
Has lead wires (terminals) concentrated on a single side for easy installation and wiring in small spaces 。
May also be used for defrosting in long-size and small-capacity operations。
Large capacity in small size。Yields high temperature in small spaces。
Improves the temperature uniformity of metallic blocks，etc。by changing the winding pitches of the heating wires。
Application examples
Keeping mold warmth、preventing freezing、icemakers、and medical equipment。
etc。
Precautions
These heaters are available in length from 30 mm to 1500 mm。
Use them in water or inserting metallic molds in contact with the objects to be heated。
Reduce the surface temperature when using them in air。
INCOLOY800
Available diameter : ø3.0~ø25.4
Details of contents : Ni 30～35, Cr 17～23, Ti 0.15~0.6, Mn 1.5MAX, Fe Bal。
Proper environment : Air heating，Heating in water。
Limit service temperature(UL) : Depends on the use environment。
Features
Has lead wires (terminals) concentrated on a single side for easy installation and wiring in small spaces。
May also be used for defrosting in long-size and small-capacity operations。
Large capacity in small size. Yields high temperature in small spaces。
Improves the temperature uniformity of metallic blocks by changing the winding pitches of the heating wires。
Application examples
Keeping mold warmth、preventing freezing、icemakers、and medical equipment。
etc。
Precautions
Tease heaters are available in length from 30 mm to 1500 mm。
Use them in water or inserting metallic molds in contact with the objects to be heated。
Reduce the surface temperature when using them in air
