| Acting type | Double acting |
|---|---|
| Tube I.D. (mm) | 20, 25, 32, 40, 50, 63, 80, 100 |
| Port size | 20,25: M5×0.8, 32~100: G1/8 |
| Medium | Air |
| Operating pressure range | 0.05~1 MPa |
| Proof pressure | 1.5 MPa |
| Ambient temperature | －5℃~＋60℃ (No freezing) |
| Available speed range | 50~500 mm/sec |
| Lubrication | Without lubrication |
| Cushion | Rubber bumpper |
| Stroke length tolerance | ＋0~＋1.0 mm (※) |
| Sensor switch | RDT, RQT, RCI |
| Remark | (※) Stroke length tolerance does not include the amount of bumper change. |
