1
Model: ACS-W(SA) series
Name: Electronic scale, electronic scale
Choose suitable electronic scales, bench scales, and scale products.
1. Weighing range, accuracy.
2. The size of the countertop to ensure that the material can be put in suitably.
3. Whether waterproof function is required.
Model name Measurement range resolution Countertop size
ACS-W(SA)-1.5 Electronic scale, electronic scale 1.5kg 0.1g 230*290 mm
ACS-W(SA)-3 Electronic scale, electronic scale 3kg 0.2g 230*290 mm
ACS-W(SA)-7.5 Electronic scale, electronic scale 7.5kg 0.5g 230*290 mm
ACS-W(SA)-15 Electronic scale, electronic scale 15kg 1g 230*290 mm
ACS-W(SA)-30 Electronic scale, electronic scale 30kg 2g 230*290 mm
AWH-3 Electronic scale, electronic scale 3kg 0.1g 230*280 mm
2
Model: ACS-C(AE) series
Name: Counting electronic scale, electronic scale
Choose suitable electronic scales, bench scales, and scale products.
1. Weighing range, accuracy.
2. The size of the countertop to ensure that the material can be put in suitably.
3. Whether waterproof function is required.
Model name Measurement range resolution Countertop size
ACS-C(AE)-1.5 Counting electronic scale, electronic scale 1.5kg 0.1g 230*280 mm
ACS-C(AE)-3 Counting electronic scale, electronic scale 3kg 0.2g 230*280 mm
ACS-C(AE)-7.5 Counting electronic scale, electronic scale 7.5kg 0.5g 230*280 mm
ACS-C(AE)-15 Counting electronic scale, electronic scale 7.5kg 1g 230*280 mm
ACS-C(AE)-30 Counting electronic scale, electronic scale 30kg 2g 230*280 mm
3
Model: ALH-Z2 series
Name: High precision electronic scale, electronic scale
Choose suitable electronic scales, bench scales, and scale products.
1. Weighing range, accuracy.
2. The size of the countertop to ensure that the material can be put in suitably.
3. Whether waterproof function is required.
Model name Measurement range resolution Countertop size
ALH-Z2-3 High precision electronic scale, electronic scale 3kg 0.05g 246*290 mm
ALH-Z2-6 High precision electronic scale, electronic scale 6kg 0.1g 246*290 mm
ALH-Z2-12 High precision electronic scale, electronic scale 12kg 0.2g 246*290 mm
ALH-Z2-30 High precision electronic scale, electronic scale 30kg 0.5g 246*290 mm
4
Model: AWH-TW-FSB series
Name: bench scale, weighing scale, electronic scale
Choose suitable electronic scales, bench scales, and scale products.
1. Weighing range, accuracy.
2. The size of the countertop to ensure that the material can be put in suitably.
3. Whether waterproof function is required.
Model name Measurement range resolution Countertop size
AWH-TW-FSB-30-400*500 Bench scales, scales, electronic scales 30kg 2g 400*500 mm
AWH-TW-FSB-30-420*520 Bench scales, scales, electronic scales 30kg 2g 420*520 mm
AWH-TW-FSB-75-400*500 Bench scales, scales, electronic scales 75kg 5g 400*500 mm
AWH-TW-FSB-75-420*520 Bench scales, scales, electronic scales 75kg 5g 420*520 mm
AWH-TW-FSB-150-400*500 Bench scales, scales, electronic scales 150kg 10g 400*500 mm
AWH-TW-FSB-150-420*520 Bench scales, scales, electronic scales 150kg 10g 420*520 mm
5
Model: V8-I single-layer series
Name: Single-layer small weighbridge
Choose the right weighbridge product.
1. Weighing range, 1-10 tons, no matter how large as 10-25 tons, can be done.
2. Resolution, generally according to the standard to do 0.2, 0.5-2kg, if you have special requirements, you can tell us, we will choose a higher precision sensor.
3. Countertop size, refer to the table, non-standard can be made.
4. Material: The standard is carbon steel, if you need all stainless steel, you can do it.
5. Ordinary models, and ultra-low countertop models, choose to buy according to your needs.
Model name Maximum weighing resolution Table size There are multiple specifications
for the same weighing 1 line represents 1 specification Material Be sure to confirm before
purchasing The thickness of the plate will vary according to the size.
V8-I-1 Single-layer small weighbridge 1t 0.2kg 0.8m* 0.8m*90mm
1m*1m*90mm
1.2m*1.2m*90mm
1.2m*1.5m *100mm
1.5m*1.5m*100mm
1.5m* 2m*130mm
1.5m*3m*130mm
2m* 2m*130mm
2m*3m*130mm 1. Carbon steel (standard model)
2. All stainless steel According to the load, the size of the countertop.
We use different steels with a thickness of 4, 5, 6, 8, 10mm.
If you have special requirements for the thickness of the plate, please let us know in advance,
we will use thicker steel plates than the standard to make it.
The cost will be higher.
V8-I-2 Single-layer small weighbridge 2t 0.5kg ditto ditto ditto
V8-I-3 Single-layer small weighbridge 3t 0.5kg ditto ditto ditto
V8-I-5 Single-layer small weighbridge 5t 1kg ditto ditto ditto
V8-I-8 Single-layer small weighbridge 8t 2kg ditto ditto ditto
V8-I-10 Single-layer small weighbridge 10t 2kg ditto ditto ditto
6
Model: V8-II double-layer series
Name: Double-layer small weighbridge
Choose the right weighbridge product.
1. Weighing range, 1-10 tons, no matter how large as 10-25 tons, can be done.
2. Resolution, generally according to the standard to do 0.2, 0.5-2kg, if you have special requirements, you can tell us, we will choose a higher precision sensor.
3. Countertop size, refer to the table, non-standard can be made.
4. Material: The standard is carbon steel, if you need all stainless steel, you can do it.
5. Ordinary models, and ultra-low countertop models, choose to buy according to your needs.
Model name Maximum weighing resolution Table size There are multiple specifications
for the same weighing 1 line represents 1 specification Material Be sure to confirm before
purchasing The thickness of the plate will vary according to the size.
V8-II-1 (Double-layer) Double-decker small weighbridge 1t 0.2kg 0.8m* 0.8m*90mm
1m*1m*90mm
1.2m*1.2m*90mm
1.2m*1.5m *100mm
1.5m*1.5m*100mm
1.5m* 2m*130mm
1.5m*3m*130mm
2m* 2m*130mm
2m*3m*130mm 1. Carbon steel (standard model)
2. All stainless steel According to the load, the size of the countertop.
We use different steels with a thickness of 4, 5, 6, 8, 10mm.
If you have special requirements for the thickness of the plate, please let us know in advance,
we will use thicker steel plates than the standard to make it.
The cost will be higher.
V8-II-2 (Double-layer) Double-decker small weighbridge 2t 0.5kg ditto ditto ditto
V8-II-3 (Double-layer) Double-decker small weighbridge 3t 0.5kg ditto ditto ditto
V8-II-5 (Double-layer) Double-decker small weighbridge 5t 1kg ditto ditto ditto
V8-II-8 (Double-layer) Double-decker small weighbridge 8t 2kg ditto ditto ditto
V8-II-10 (Double-layer) Double-decker small weighbridge 10t 2kg ditto ditto ditto
7
Model: V8-I single-layer ultra-low series
Name: Single-layer ultra-low countertop small weighbridge
Choose the right weighbridge product.
1. Weighing range, 1-10 tons, no matter how large as 10-25 tons, can be done.
2. Resolution, generally according to the standard to do 0.2, 0.5-2kg, if you have special requirements, you can tell us, we will choose a higher precision sensor.
3. Countertop size, refer to the table, non-standard can be made.
4. Material: The standard is carbon steel, if you need all stainless steel, you can do it.
5. Ordinary models, and ultra-low countertop models, choose to buy according to your needs.
Model name Maximum weighing resolution Table size There are multiple specifications
for the same weighing 1 line represents 1 specification Material Be sure to confirm before
purchasing The thickness of the plate will vary according to the size.
V8-I-1 (Single-Layer Ultra-Low) Single-layer ultra-low table small weighbridge 1t 0.2kg 0.8m*0.8m*35mm
1m*1m*40mm
1.2m*1.2m*45mm
1.2m*1.5m*45mm 1. Carbon steel (standard model)
2. All stainless steel According to the load, the size of the countertop.
We use different steels with a thickness of 4, 5, 6, 8, 10mm.
If you have special requirements for the thickness of the plate, please let us know in advance,
we will use thicker steel plates than the standard to make it.
The cost will be higher.
V8-I-1.5 (Single-Layer Ultra-Low) Single-layer ultra-low table small weighbridge 1.5t 0.5kg ditto ditto ditto
V8-I-2 (Single-Layer Ultra-Low) Single-layer ultra-low table small weighbridge 2t 0.5kg ditto ditto ditto
8
Model: V8-II double-layer ultra-low series
Name: Double-layer ultra-low table small weighbridge
Choose the right weighbridge product.
1. Weighing range, 1-10 tons, no matter how large as 10-25 tons, can be done.
2. Resolution, generally according to the standard to do 0.2, 0.5-2kg, if you have special requirements, you can tell us, we will choose a higher precision sensor.
3. Countertop size, refer to the table, non-standard can be made.
4. Material: The standard is carbon steel, if you need all stainless steel, you can do it.
5. Ordinary models, and ultra-low countertop models, choose to buy according to your needs.
Model name Maximum weighing resolution Table size There are multiple specifications
for the same weighing 1 line represents 1 specification Material Be sure to confirm before
purchasing The thickness of the plate will vary according to the size.
V8-I-1 (Double-Layer Ultra-Low) Double-layered ultra-low table small weighbridge 1t 0.2kg 0.8m*0.8m*35mm
1m*1m*40mm
1.2m*1.2m*45mm
1.2m*1.5m*45mm 1. Carbon steel (standard model)
2. All stainless steel According to the load, the size of the countertop.
We use different steels with a thickness of 4, 5, 6, 8, 10mm.
If you have special requirements for the thickness of the plate, please let us know in advance,
we will use thicker steel plates than the standard to make it.
The cost will be higher.
V8-I-1.5 (Double Layer Ultra-low) Double-layered ultra-low table small weighbridge 1.5t 0.5kg ditto ditto ditto
V8-I-2 (Double Layer Ultra-Low) Double-layered ultra-low table small weighbridge 2t 0.5kg ditto ditto ditto
9
Model: AWH-TW-FSB-75 series: 30-75 kg, accuracy 2-20g
Name: Bench Scale, Weighing Scale, Electronic Bench Scale (AWH-TW-FSB-30, AWH-TW-FSB-75, AWH
Weighing range: 30-75kg
Accuracy: d=2-20g, 1/15000
Pan size:
400 x 500mm
420 x 520mm
450 x 550mm
600 x 800mm
10
Model: AWH-TW-FSB-150 series: 150-300 kg, accuracy 2-20g
Name: Bench Scale, Weighing Scale, Electronic Bench Scale (AWH-TW-FSB-30, AWH-TW-FSB-75, AWH
Weighing range: 150-300kg
Accuracy: d=2-20g, 1/15000
Pan size:
400 x 500mm
420 x 520mm
450 x 550mm
600 x 800mm
11
Model: AWH-TW-FSB-600: Large scale, large 600kg, accuracy 50g
Name: bench scale, weighing scale, electronic bench scale
Weighing range: 600Kg
Accuracy: 50g, 1/15000
Pan size:
600 x 800mm
12
Model: BW series: waterproof, 6-30kg, accuracy 2-10g
Name: Bench scale, weighing scale, electronic bench scale (waterproof function).
This one is waterproof,
weighing range: 6-30kg
Accuracy: 2-10g
Scale pan size: 280(W) x 280(D)mm
13
Model: BW series: waterproof, 60-150kg, accuracy 20-50g
Name: Bench scale, weighing scale, electronic bench scale (waterproof function).
This one is waterproof,
weighing range: 60-150kg
Accuracy: 20-50g
Scale pan size: 405(W) x 525(D)mm
14
Model: V8 series: small weighbridge, 1-10 tons, accuracy 0.3-3kg
Name: Weighbridge, Small Weighbridge, Electronic Weighbridge
This electronic weighbridge can also be equipped with a mobile trolley to become a mobile weighbridge.
V8 series:
Weighing range: 1-10 tons
Accuracy: 1/30000
Table: (table size specifications can be customized according to customer requirements)
0.8×0.8, 0.8×1
1×1, 1×1.2
1.2×1.2, 1.2×1.5
1.5×1.5, 1.5×2
2×2, 2×4
15
Model: TCS-W series
Name: Weighing table scale
• TCS-W (XSB) industrial weighing electronic bench scales that provide the highest accuracy and durability in harsh working environments.
• External accuracy up to 1/15,000, using high-precision sensors, high reliability (tens of thousands of times, weighing accuracy is still not affected).
• Built-in MODBUS communication protocol, which can complete a simple system independently or connect to a PLC to achieve a complex system.
Model name Measurement range
TCS-W-30kg(XSB) Weighing table scales Max=30kg e=10g d=2g
TCS-W-60kg(XSB) Weighing table scales Max=60kg e=20g d=5g
TCS-W-150kg(XSB) Weighing table scales Max=150kg e=50g d=10g
TCS-W-300kg(XSB) Weighing table scales Max=300kg e=100g d=20g
