| luid medium | Air (JIS B 8392-1:Class1.2.1～2.4.3 compliant), Vacuum |
|---|---|
| Operating pressure range | 0.3~0.7 MPa |
| Working vacuum range | -100~0 kPa |
| Operating temp. range | 5~50℃(No freezing) |
| Operating humidity range | 35~85% RH (No dew condensation) |
| Vibration / Impact resistance | Max. 50m/s2 / Max. 150m/s2 |
| Protective structure | Equivalent to IEC IP40 |
| Lubrication | Not required |
| Proof pressure (Air supply circuit) | 1.05 MPa |
| Proof pressure (Vacuum circuit) | 0.2 MPa |
