| Acting type | Double acting |
|---|---|
| Tube I.D. (mm) | 5.2,8,12,16,20 |
| Stroke | 10~100mm |
| Port size | M3×0.5, M5×0.8 |
| Air | Air |
| Operating pressure range | 0.15~0.7 MPa |
| Proof pressure | 1 MPa |
| Ambient temperature | －10~＋60℃ (No freezing) |
| Available speed range | 50~500 mm/sec |
| Cushion spring stroke | 2mm |
| Cushion spring pressure | 0.8 at the time of withdrawal, 2 at the time of acting |
| Lubricator | Not required |
| Cushion | Rubber bumper |
| Stroke length tolerance | +1.0 0 |
| Stroke adjuster range | Extend 5mm / Retract 5mm |
| Sensor switch | RCE, RCE1, RDFEV |
| Weight | 22~1351g |
