Bore No. | 6A, 8A | ||||||||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Port size | G1/8, G1/4 | ||||||||||||||||||||||||||||||||||||
No. of port | 5 | ||||||||||||||||||||||||||||||||||||
No. of position | 2 | ||||||||||||||||||||||||||||||||||||
Medium | Air | ||||||||||||||||||||||||||||||||||||
Operating pressure range | 0.2~0.8 MPa | ||||||||||||||||||||||||||||||||||||
Proof pressure | 1 MPa | ||||||||||||||||||||||||||||||||||||
Flow | 980 l/min | ||||||||||||||||||||||||||||||||||||
Effective orifice | 18 mm2 | ||||||||||||||||||||||||||||||||||||
Response time | 38 ms | ||||||||||||||||||||||||||||||||||||
Ambient temperature | -5~+50℃ (No freezing) | ||||||||||||||||||||||||||||||||||||
Voltage | AC110V, AC220V (50/60)Hz, AC/DC 24V | ||||||||||||||||||||||||||||||||||||
Power consumption-Standard | AC=4.8/4.4VA, 6/4.9VA, DC=2W | ||||||||||||||||||||||||||||||||||||
Power consumption-Power saving | DC=Start: 2W(*) Power saving: 0.5W | ||||||||||||||||||||||||||||||||||||
Available voltage range | ±10% | ||||||||||||||||||||||||||||||||||||
Insulation class | F class | ||||||||||||||||||||||||||||||||||||
Weight | 233 g, 343 g | ||||||||||||||||||||||||||||||||||||
Remark | * Power saving covert time 100ms.
|
