| Acting type | Double acting |
|---|---|
| Size | 50, 66, 80, 100, 125, 160, 200, 300 |
| Medium | Air |
| Stroke per-jaw | 4~30 mm |
| Effective external gripping force (N) (※1) | 69~3283 N |
| Operating pressure range | 0.3~0.8 MPa |
| Ambient temperature | ＋5℃~＋80℃ |
| Close/Open time | 0.02 ~ 0.45 s |
| Lubrication | Not required |
| Compressed air consumption | 4.1 ~ 1000 cm3 |
| Accessories | Mounting block, Accessory kits |
| Sensor switch | 2 wire RDFE(V): Non-contact 3 wire RNFE(V): NPN, RPFE(V): PNP |
| Proximity sensor | RJY |
| Weight | 0.14~14.2 kg |
| Recom. work piece weight | 0.85~32 kg |
| Remark | ※1. Under the condition of clamping length 40mm and operation pressure 0.6 MPa. ※2. Regularly relubricate the finger to increase the service life. Please contact us for grease info. |
MCHS-OS
| Acting type | Double acting |
|---|---|
| Size | 80, 100, 125 mm |
| Stroke per-jaw | Standaerd: 8, 10, 12 mm High: 4, 5, 6 mm |
| Effective external gripping force (N) (※) | Standaerd: 314, 372, 684 mm High: 591, 701, 1287 mm |
| Close / Open time (s) | Open: 0.05~0.12 Close: 0.03~0.08 |
| Medium | Air |
| Operating pressure range | 0.4~0.6 MPa |
| Compressed air consumption(cm3) | 42~129 cm3 |
| Ambient temperature | ＋5℃~＋80℃ |
| Lubrication | Not required |
| Sensor switch | 2 wire: RDFE(V): Non-contact 3 wire: RNFE(V): NPN, RPFE(V): PNP |
| Accessories | Accessory kits |
| Weight (kg) | 0.57~1.74 kg |
| Remark | ※ Under the condition of clamping length 40mm and operation pressure 0.6 MPa. |
