- 25, φ26, φ26.8, φ30, φ33, φ40, φ48, φ50
- ・Max. power: 350 W
- ・Max. motor speed: 80,000 min-1
- ・28 types of motor spindles (straight, angle head, automatic tool change, air bearing, antistatic, etc.)
- ・Spindle accuracy: within 1 μm
- ・Can be mounted on CNC lathes, robots, and special purpose machines
Features
Available in separate type (combination type) and one-piece type (all-in-one type)
-
・Good point of separate typeSpindle and motor can be freely combined and selected depending on the processing application.
Spindles and motors with various characteristics enable a variety of solutions. -
・Good point of one-piece typeThe overall length of the motor spindle is shorter than that of the separate type, making it easier to mount on small space-saving CNC lathes and special purpose machines.
Supports φ6.35 tools
Tools with shank diameters up to φ6.35 can be attached.
Please note that the attachable shank diameter size varies by model.
Please note that the attachable shank diameter size varies by model.
Supports various mounting methods
Three types of products are available to meet your mounting needs.
-
・Straight typeNeed to make a holder to mount on a machine -
・Straight type + Grip RingAttach the GR-30 Grip Ring (sold separately) to the spindle
Eliminates the need to make your own holder -
・Flange typeSpindle and holder integrated type
Easy to mount on a machine
Motors with various characteristics
Our lineup of motors with various characteristics enables selecting the motor depending on processing application.
-
Torque & power curve
80,000 min-1 motor spindle
-
Torque & power curve
60,000 min-1 motor spindle
-
Torque & power curve
30,000 min-1 motor spindle
E3000
ELECTRIC SPINDLES
20mm (0.79\u201d), 22.8mm (0.89\u201d), 25mm (0.98\u201d), 25.4mm (1\u201d), 30mm (1.18\u201d) Spindle dia., 60,000/80,000rpm Max RPM, 350W (0.47HP) Max Power
Series Description
The E3000 Series employs a high-speed, ultra-quiet brushless motor. A high-performance system and state of the art design provides high-speed machining and a variety of safety functions.
Additional details
Features
- Max motor speed 60,000/80,000 min-1(rpm)
- Maximum motor output with 350W power supply
- Motor spindle diameter
- Air-cooling system
- Spindle accuracy
- High rigidity, short body
- Motor connector attaches directly to the back of the motor/spindle
- Power source auto detection
- Protection system, external Input/Output control signal
- Use E2550 Motor and Spindle with E3000 Control Unit
- ø0.897″(ø22.8 mm) spindle usage
- Centering mode switch
