Functional principle Photoelectric retro-reflective sensor
Functional principle detail With minimum distance to reflector (dual lens system)
Dimensions (W x H x D) 20 mm x 50 mm x 39 mm
Housing design (light emission) Rectangular
Sensing range max.
0.08 m … 15 m 1)
0.08 m … 12 m 2)
Sensing range
0.15 m … 12 m 1)
0.15 m … 10 m 2)
Type of light Visible red light
Light source PinPoint LED 3)
Light spot size (distance) Ø 58 mm (5 m)
Wave length 625 nm
Adjustment Potentiometer, 270°
