Dao phay chữ V|Tungsten Carbide Center V Endmill|Kyowa|KSV-26028(2.8X6X45 S2)

ferential Cutting Conditions

Workpiece	Carbon Steel / General Structural Steel S55C / SS						Alloy Steel / Tool Steel SCM / SKT / SKS / SKD						Aluminum Alloy ADC・AC						Cast iron FC / FCD
Kinds of Processing	Chamfer Cutting Side Cutting		V Groove Cutting		Center Cutting Drilling		Chamfer Cutting Side Cutting		V groove Cutting		Center Cutting Drilling		Chamfer Cutting Side Cutting		V Groove Cutting		Center Cutting Drilling		Chamfer Cutting Side Cutting		V Groove Cutting		Center Cutting Drilling
Flute Diameter mm	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min	Revolution min-1	Feed ㎜/min
0.5~0.6	10~18	0.002~0.01	10~18	0.002~0.01	10~18	0.01~0.02	10~18	0.002~0.01	8~15	0.001~0.003	8~15	0.004~0.01	25~35	0.006~0.016	25~35	0.006~0.016	25~35	0.02~0.04	25~35	0.006~0.016	25~35	0.006~0.016	25~35	0.01~0.03
0.7~0.9	15~25	0.006~0.02	15~25	0.006~0.02	15~25	0.01~0.03	10~18	0.006~0.02	10~18	0.001~0.003	10~18	0.006~0.02	30~40	0.01~0.02	30~40	0.01~0.02	30~40	0.03~0.07	30~40	0.01~0.02	30~40	0.01~0.02	30~40	0.01~0.03
1~2	15~25	0.01~0.03	15~25	0.01~0.03	15~25	0.02~0.04	10~20	0.006~0.02	10~20	0.002~0.005	10~20	0.008~0.02	40~80	0.02~0.04	40~80	0.02~0.04	40~80	0.04~0.08	30~40	0.02~0.04	30~45	0.02~0.04	30~45	0.03~0.06
2~3	15~25	0.01~0.03	15~25	0.01~0.03	15~25	0.02~0.04	10~20	0.006~0.02	10~20	0.002~0.005	10~20	0.01~0.03	40~80	0.02~0.04	40~80	0.02~0.04	40~80	0.06~0.1	30~45	0.02~0.04	30~45	0.02~0.04	30~45	0.06~0.08
3~4	15~25	0.01~0.03	15~25	0.01~0.03	15~25	0.02~0.04	10~20	0.006~0.02	10~20	0.002~0.005	10~20	0.01~0.03	40~80	0.02~0.04	40~80	0.02~0.04	40~80	0.06~0.1	30~45	0.02~0.04	30~45	0.02~0.04	30~45	0.06~0.08
4~5	20~30	0.01~0.04	20~30	0.01~0.04	20~30	0.02~0.05	15~25	0.008~0.03	15~25	0.003~0.01	15~25	0.01~0.04	40~80	0.02~0.05	40~80	0.02~0.05	40~80	0.06~0.12	30~50	0.02~0.05	30~50	0.02~0.05	30~50	0.06~0.1
5~6	20~30	0.02~0.05	20~30	0.02~0.05	20~30	0.02~0.05	15~25	0.008~0.03	15~25	0.003~0.01	15~25	0.01~0.04	40~80	0.02~0.05	40~80	0.02~0.05	40~80	0.06~0.12	30~50	0.02~0.05	30~50	0.02~0.05	30~50	0.06~0.1

Product lineup

Unit [size:mm / Retail Price:JPY]

KSV-2 90°

Code №	Flute Diameter (D)	Flute Length (ℓ)	Total Length (L)	Shank Diameter (d)	Edge Flat Diamater	Retail Price
KSV-29005	0.5	1	40	3	0.06	8,500
KSV-29006	0.6	1.2	40	3	0.06	8,500
KSV-29007	0.7	1.4	40	3	0.06	7,800
KSV-29008	0.8	1.6	40	3	0.06	7,800
KSV-29009	0.9	2	40	3	0.06	7,500
KSV-29010	1	2	45	4	0.1	7,000
KSV-29011	1.1	2.5	45	4	0.1	7,000
KSV-29012	1.2	2.5	45	4	0.1	7,000
KSV-29013	1.3	3	45	4	0.1	7,000
KSV-29014	1.4	3	45	4	0.1	7,000
KSV-29015	1.5	3	45	4	0.1	7,000
KSV-29016	1.6	3.5	45	4	0.1	7,000
KSV-29017	1.7	3.5	45	4	0.1	7,000
KSV-29018	1.8	4	45	4	0.1	7,000
KSV-29019	1.9	4	45	4	0.1	7,000
KSV-29020	2	4	45	4	0.2	7,000
KSV-29021	2.1	4.5	45	4	0.2	7,800
KSV-29022	2.2	4.5	45	4	0.2	7,800
KSV-29023	2.3	5	45	4	0.2	7,800
KSV-29024	2.4	5	45	4	0.2	7,800
KSV-29025	2.5	5	45	4	0.2	7,800
KSV-29026	2.6	6	45	4	0.2	7,800
KSV-29027	2.7	6	45	4	0.2	7,800
KSV-29028	2.8	6	45	4	0.2	7,800
KSV-29029	2.9	6	45	4	0.2	7,800
KSV-29030	3	6	45	4	0.2	7,800
KSV-29035	3.5	7	50	6	0.2	10,100
KSV-29040	4	8	50	6	0.2	10,100
KSV-29045	4.5	9	50	6	0.3	11,700
KSV-29050	5	10	60	6	0.3	11,700
KSV-29055	5.5	11	60	6	0.3	12,800
KSV-29060	6	12	60	6	0.3	12,800

KSV-2 60°

Code №	Flute Diameter (D)	Flute Length (ℓ)	Total Length (L)	Shank Diameter (d)	Edge Flat Diamater	Retail Price
KSV-26005	0.5	1	40	3	0.06	9,400
KSV-26006	0.6	1.2	40	3	0.06	9,400
KSV-26007	0.7	1.4	40	3	0.06	9,400
KSV-26008	0.8	1.6	40	3	0.06	8,500
KSV-26009	0.9	2	40	3	0.06	8,200
KSV-26010	1	2	45	4	0.08	7,800
KSV-26011	1.1	2.5	45	4	0.08	7,800
KSV-26012	1.2	2.5	45	4	0.08	7,800
KSV-26013	1.3	3	45	4	0.08	7,800
KSV-26014	1.4	3	45	4	0.08	7,800
KSV-26015	1.5	3	45	4	0.08	7,800
KSV-26016	1.6	3.5	45	4	0.08	7,800
KSV-26017	1.7	3.5	45	4	0.08	7,800
KSV-26018	1.8	4	45	4	0.08	7,800
KSV-26019	1.9	4	45	4	0.08	7,800
KSV-26020	2	4	45	4	0.1	7,800
KSV-26021	2.1	4.5	45	4	0.1	8,500
KSV-26022	2.2	4.5	45	4	0.1	8,500
KSV-26023	2.3	5	45	4	0.1	8,500
KSV-26024	2.4	5	45	4	0.1	8,500
KSV-26025	2.5	5	45	4	0.1	8,500
KSV-26026	2.6	6	45	4	0.1	8,500
KSV-26027	2.7	6	45	4	0.1	8,500
KSV-26028	2.8	6	45	4	0.1	8,500
KSV-26029	2.9	6	45	4	0.1	8,500
KSV-26030	3	6	45	4	0.1	8,500
KSV-26040	4	8	50	6	0.15	11,200
KSV-26050	5	10	60	6	0.2	12,900
KSV-26060	6	12	60	6	0.2	14,000

KSV-2 120°

Code №	Flute Diameter (D)	Flute Length (ℓ)	Total Length (L)	Shank Diameter (d)	Edge Flat Diamater	Retail Price
KSV-212005	0.5	1	40	3	0.06	8,500
KSV-212006	0.6	1.2	40	3	0.06	8,500
KSV-212007	0.7	1.4	40	3	0.06	7,800
KSV-212008	0.8	1.6	40	3	0.06	7,800
KSV-212009	0.9	2	40	3	0.06	7,500
KSV-212010	1	2	45	4	0.1	7,000
KSV-212011	1.1	2.5	45	4	0.1	7,000
KSV-212012	1.2	2.5	45	4	0.1	7,000
KSV-212013	1.3	3	45	4	0.1	7,000
KSV-212014	1.4	3	45	4	0.1	7,000
KSV-212015	1.5	3	45	4	0.1	7,000
KSV-212016	1.6	3.5	45	4	0.1	7,000
KSV-212017	1.7	3.5	45	4	0.1	7,000
KSV-212018	1.8	4	45	4	0.1	7,000
KSV-212019	1.9	4	45	4	0.1	7,000
KSV-212020	2	4	45	4	0.2	7,000
KSV-212021	2.1	4.5	45	4	0.2	7,800
KSV-212022	2.2	4.5	45	4	0.2	7,800
KSV-212023	2.3	5	45	4	0.2	7,800
KSV-212024	2.4	5	45	4	0.2	7,800
KSV-212025	2.5	5	45	4	0.2	7,800
KSV-212026	2.6	6	45	4	0.2	7,800
KSV-212027	2.7	6	45	4	0.2	7,800
KSV-212028	2.8	6	45	4	0.2	7,800
KSV-212029	2.9	6	45	4	0.2	7,800
KSV-212030	3	6	45	4	0.2	7,800
KSV-212035	3.5	7	50	6	0.2	10,100
KSV-212040	4	8	50	6	0.2	10,100
KSV-212045	4.5	9	50	6	0.3	11,700
KSV-212050	5	10	60	6	0.3	11,700
KSV-212055	5.5	11	60	6	0.3	12,800
KSV-212060	6	12	60	6	0.3	12,800

KSV-2 30°

Code №	Flute Diameter (D)	Flute Length (ℓ)	Total Length (L)	Shank Diameter (d)	Edge Flat Diamater	Retail Price
KSV-23005	0.5	1	40	3	0.06	9,200
KSV-23010	1	2	45	4	0.08	7,800
KSV-23015	1.5	3	45	4	0.08	7,800
KSV-23020	2	4	45	4	0.1	7,800
KSV-23025	2.5	5	45	4	0.1	8,500
KSV-23030	3	6	45	4	0.1	8,500
KSV-23040	4	8	60	6	0.15	12,200
KSV-23050	5	10	70	6	0.2	14,100
KSV-23060	6	12	70	6	0.2	15,500

KSV-2 45°

Code №	Flute Diameter (D)	Flute Length (ℓ)	Total Length (L)	Shank Diameter (d)	Edge Flat Diamater	Retail Price
KSV-24505	0.5	1	40	3	0.06	9,200
KSV-24510	1	2	45	4	0.08	7,800
KSV-24515	1.5	3	45	4	0.08	7,800
KSV-24520	2	4	45	4	0.1	7,800
KSV-24525	2.5	5	45	4	0.1	8,500
KSV-24530	3	6	45	4	0.1	8,500
KSV-24540	4	8	60	6	0.15	12,200
KSV-24550	5	10	70	6	0.2	14,100
KSV-24560	6	12	70	6	0.2	15,500

KSV-2 70°

Code №	Flute Diameter (D)	Flute Length (ℓ)	Total Length (L)	Shank Diameter (d)	Edge Flat Diamater	Retail Price
KSV-27005	0.5	1	40	3	0.06	8,500
KSV-27010	1	2	45	4	0.08	7,000
KSV-27015	1.5	3	45	4	0.08	7,000
KSV-27020	2	4	45	4	0.1	7,000
KSV-27025	2.5	5	45	4	0.1	7,800
KSV-27030	3	6	45	4	0.1	7,800
KSV-27040	4	8	50	6	0.15	11,200
KSV-27050	5	10	60	6	0.2	12,900
KSV-27060	6	12	60	6	0.2	14,000

KSV-2 80°

Code №	Flute Diameter (D)	Flute Length (ℓ)	Total Length (L)	Shank Diameter (d)	Edge Flat Diamater	Retail Price
KSV-28005	0.5	1	40	3	0.06	8,500
KSV-28010	1	2	45	4	0.08	7,000
KSV-28015	1.5	3	45	4	0.08	7,000
KSV-28020	2	4	45	4	0.1	7,000
KSV-28025	2.5	5	45	4	0.1	7,800
KSV-28030	3	6	45	4	0.1	7,800
KSV-28040	4	8	50	6	0.15	11,200
KSV-28050	5	10	60	6	0.2	12,900
KSV-28060	6	12	60	6	0.2	14,000
