| Display section*1 *2 | Display device | |
| Screen size | ||
| Resolution | ||
| Display size | ||
| Number of displayed characters | ||
| Display color | ||
| Brightness adjustment | ||
| Registrable number of screen | ||
| Backlight | ||
| Backlight life*4 | ||
| Backlight color | ||
| Touch panel*3 *11 | Type | |
| Key size | ||
| Simultaneous press | ||
| Life | ||
| Human sensor | Detection length | |
| Detection temperature | ||
| User memory | ||
| Built-in clock precision | ||
| Battery | Type | |
| Backup target | ||
| Life | ||
| Built-in interface | RS-232 | Number of channel |
| Transmission speed | ||
| Connector shape | ||
| RS-422/485 | Number of channel | |
| Transmission speed | ||
| Connector shape | ||
| RS-422/232 | Number of channel | |
| Transmission speed | ||
| Connector shape | ||
| Application | ||
| RS-422 | Number of channel | |
| Transmission speed | ||
| Connector shape | ||
| Ethernet | Number of channel | |
| Data transfer method | ||
| Connector shape | ||
| Bus interface | Type | |
| Number of channel | ||
| RGB interface | ||
| Printer interface | ||
| USB (host) | Number of channel | |
| Maximum transfer rate | ||
| Connector shape | ||
| USB (device) | Number of channel | |
| Maximum transfer rate | ||
| Connector shape | ||
| SD memory card | ||
| CF card interface | ||
| PC card interface | ||
| Option function board interface | ||
| Memory board interface | ||
| Wireless LAN communication unit interface | ||
| Sound output interface | ||
| Buzzer sound | ||
| LED specifications | POWER LED | |
| Installation method | ||
| Panel color | ||
| Protective structure*7 | ||
| External dimensions | ||
| Panel cut dimensions | ||
| Weight (excluding a fitting) | ||
|
TFT color LCD
|
|
4.3″
|
|
480 x 272 dots
|
|
95.0 (W) x 53.8 (H) mm
(3.74 (W) x 2.12 (H) inch) |
|
16-dot standard font: 30 characters x 17 lines (two-byte characters)
12-dot standard font: 40 characters x 22 lines (two-byte characters) |
|
65536 colors
|
|
32 levels
|
|
2048
|
|
LED (not replaceable)
|
|
Approx. 50000 h (operating ambient temperature: 25°C, display intensity: 50%)
|
|
White
|
|
Analog resistive film
|
|
Minimum 2 x 2 dots*9 (per key)
|
|
Not available*5 (Only 1 point can be touched.)
|
|
1 million touches or more (operating force: 0.98 N or less)
|
|
-
|
|
-
|
|
Memory for storage (ROM) *12 : 9 MB
Life (number of write times) : 100000 times |
|
±45 seconds/month (ambient temperature: 25°C)
|
|
GT11-50BAT lithium battery
|
|
SRAM data, clock data
|
|
Approx. 5 years (ambient temperature: 25°C)
|
|
1 channel
|
|
115200, 57600, 38400, 19200, 9600, 4800 bps
|
|
9-pin connector terminal block
|
|
1 channel
|
|
115200, 57600, 38400, 19200, 9600, 4800 bps
|
|
9-pin connector terminal block
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
1 channel
|
|
100BASE-TX, 10BASE-T
|
|
RJ45 (modular jack) AUTO MDI/MDI-X
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
1 channel (rear face)
|
|
Full-Speed 12 Mbps
|
|
USB Mini-B
|
|
1 channel, SDHC compliant (maximum 32 GB) *12
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
-
|
|
Single tone (tone length adjustable)
|
|
-
|
|
Standard
|
|
Black
|
|
Front: IP67F*10
Inside control panel: IP2X |
|
128 (W) x 102 (H) x 40 (D) mm
(5.04 (W) x 4.02 (H) x 1.57 (D) inch) |
|
118 (W) x 92 (H) mm
(4.65 (W) x 3.62 (H) inch) |
|
0.4 kg
(0.88 lb) |
