Specifications
– Resistance range:
+ 30mΩ(max 35mΩ/resolution 1μΩ)
+ 3MΩ (max 3.5MΩ/resolution 100Ω)
– Accuracy: ±0.020 % rdg. ±0.007 % f.s.
– Testing current:
+ With range 30mΩ: 300mA DC
+ With range 3MΩ: 500nA DC
– Open-teminal voltage: 5.5V DC max
– Temperature measurement:
+ -10.0 to 99.9°C
+ Accuracy: ±0.50°C
+ Temperature Z2001
– Measurement:
+ Fast: 50Hz: 21ms, 60Hz: 18ms
+ Medium: 101ms
+ Slow: 401ms
– Function:
+ Temperature correction, comparator(ABS/REF%)
+ Display digit count selection function 4 digits, 5 digits
+ Auto hold, avẻaging
– Communication interface:
+ RS-232C, printer (RS232C), USB
+ Communication monitor function, output data function
– Power supply:
+ 100 to 240 V AC, 50/60 Hz
+ rate power consumption: 15VA
– Dimensions: 215x80x166mm
– mass: 1kg
– Supplied Accessories:
+ Power cord x1, Clip type lead L2101 ×1,Male EXT I/O connector ×1
+ Intruction manual, Application disc x1, Cable USB x1, fulse x1
– The warranty period: 12 month
| Resistance range | 30 mΩ (35.000 mΩ display Max., 1 μΩ resolution) to 3 MΩ range (3.5000 MΩ display Max., 100 Ω resolution), 9 steps Measurement accuracy: ±0.020 % rdg. ±0.007 % f.s. |
| Testing current | [at 30 mΩ range] 300 mA DC to [at 3 MΩ range] 500 nA DC |
| Open-terminal voltage | 5.5 V DC max. |
| Temperature measurement | -10.0 to 99.9°C, accuracy: ±0.50°C (Temperature Sensor Z2001 and RM3544/RM35440-01 combined accuracy) |
| Measurement speed | FAST (50Hz: 21ms, 60Hz: 18ms) / MED (101ms) / SLOW (401ms) |
| Display refresh rate | N/A |
| Functions | Temperature correction, comparator (ABS/REF%), key-lock (OFF, menu lock, all lock), display digit count selection function (5 digits/ 4 digits), automatic power supply frequency settings (AUTO/50Hz/60Hz), scaling, judgment sound setting, auto hold, averaging, panel store/panel load |
| Memory storage | N/A |
| Communication interfaces | [Only RM3544-01] Select from RS-232C, PRINTER (RS-232C), or USB Remote function, communications monitor function, data output function |
| Power supply | 100 to 240 V AC, 50/60 Hz, Rated power consumption: 15 VA |
| Dimensions, mass | 215 mm (8.46 in) W × 80 mm (3.15 in) H × 166 mm (6.54 in) D mm [RM3544] 0.9 kg (31.7 oz) [RM3544-01] 1.0 kg (35.3 oz) |
| Supplied accessories | [RM3544] Power cord ×1, Clip type lead L2101 ×1, Instruction manual ×1, Extra fuse ×1 [RM3544-01] Power cord ×1, Clip type lead L2101 ×1, Male EXT I/O connector ×1, Instruction manual ×1, Application disc ×1, USB cable (A-to-B type) ×1, Extra fuse ×1 |
