Product Line |
VEXTA® |
Motor Type |
Closed Loop |
Motor Frame Size |
2.36 in. sq. |
Power Input |
AC |
Shaft/Gear Type |
Round Shaft (No Gearhead) |
Shaft |
Single |
Electromagnetic Brake |
Equipped |
Resolution (Resolution Setting: 1000 P/R) |
0.36 °/Pulse |
Rotor Inertia (oz-in2) |
3.1 oz-in2 |
RoHS Compliant |
Yes |
Safety Standards |
ULCSAENCE |
CE Marking |
Low Voltage DirectivesEMC Directives |
California Proposition 65 |
⚠ CA WARNING Cancer risk from exposure to Nickel. See www.P65Warnings.ca.gov Risk of reproductive harm from exposure to Di-n-hexyl phthalate (DnHP). See www.P65Warnings.ca.gov Risk of cancer and reproductive harm from exposure to Di(2-ethylhexyl phthalate (DEHP). See www.P65Warnings.ca.gov See “?” or copy/paste www.P65Warnings.ca.gov in your browser. |
Insulation Class |
Class B (266ºF [130ºC]), UL/CSA: Recognized as Class A 221ºF (105ºC) |
Insulation Resistance |
100 MΩ minimum when measured by a 500 VDC megger between the frame-windings and frame-electromagnetic brake windings. |
Dielectric Strength |
Sufficient to withstand the following for one minute: Frame-Windings 1.5 kV 50 or 60 Hz, Frame-Electromagnetic brake windings 1.0kV 50 or 60 Hz |
Ambient Humidity |
85% or less (noncondensing) |
Operating Atmosphere |
No corrosive gases, dust, water or oil. |
Permissible Thrust Load |
The permissible thrust load shall be no greater than the motor mass |
