| Medium | Compressed air |
|---|---|
| Operating Temperature | -10 … 50 °C, 14 … 122 °F |
| Operating Pressure | 1 … 10 bar, 15 … 145 psi |
| Port Size | G1/4 |
| Actuation | Solenoid pilot / Air spring return |
| Coil Code | 3030 |
| Valve operation | 5/2 |
| Flow | 1325 l/m, 47 scfm |
| Materials – Body | Aluminium |
| Materials – Seals | Nitrile rubber (NBR) |
| Certification – IP Rating | IP65 with connector (excluded) |
| Dimensions – Height | 30 mm |
| Dimensions – Length | 139.6 mm |
| Dimensions – Width | 55 mm |
| Weight | 0.44 kg |
| Country of Origin | Germany |
| Range | 26230 |
| Series | 2623 Inline Valves |
| Brand | IMI Herion |
