- Nominal width of Laval nozzle0.95 mm
- Width dimension18 mm
- Muffler construction typeClosed
- Mounting positionAny
- Ejector characteristicsHigh vacuum
- Grade of filtration≤40 µm
- Manual overrideNon-detenting
- Integrated functionEjector pulse valve, electric Flow control On/off valve, electric Filter Non-return valve
- Symbol00991305
- Valve functionClosed
- Operating pressure0.2 MPa … 0.8 MPa
- Operating pressure2 bar … 8 bar
- Operating pressure29 psi … 116 psi
- Max. vacuum85 %
- Nominal operating pressure0.6 MPa
- Nominal operating pressure6 bar
- Nominal operating pressure87 psi
- Air supply time at nominal operating pressure with ejector pulse2.04 s
- DC operating voltage range21.6 V … 26.4 V
- Duty cycle100%
- Certificationc UL us – Recognized (OL)
- Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot mediaOperation with oil lubrication not possible
- Corrosion resistance class (CRC)2 – Moderate corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Temperature of medium0 °C … 60 °C
- Degree of protectionIP65
- Ambient temperature0 °C … 60 °C
- Product weight240 g
- Electrical connectionPlug
- Type of mountingWith through-hole With internal thread
- Pneumatic connection 1G1/8
- Pneumatic connection 3Pneumatic muffler integrated
- Vacuum connectionG1/8
- Note on materialsRoHS-compliant
- Seals materialNBR
- Female nozzle materialBrass, nickel-plated
- Compressed air filter materialPA
- Material of filter housingPC
- Housing materialWrought aluminum alloy
- Muffler materialPE POM
- Material of pistonPOM
- Material of jet nozzleBrass, nickel-plated
