- Stroke10 mm … 3000 mm
- Piston diameter32 mm
- CushioningPneumatic cushioning, adjustable at both ends Shock absorber, hard characteristic curve
- Mounting positionoptional
- GuideRecirculating ball bearing guide
- Coupling designPositive-locking (slot)
- Position detectionVia proximity switch
- Symbol00991254
- Operating pressure0.2 MPa … 0.8 MPa
- Operating pressure2 bar … 8 bar
- Mode of operationDouble-acting
- Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
- Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
- Corrosion resistance class CRC0 – No corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Ambient temperature-10 °C … 60 °C
- Cushioning length20 mm
- Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke483 N
- Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke483 N
- Moving mass890 g
- Moving mass for 0 mm stroke890 g
- Additional moving mass per 10 mm stroke69 g
- Basic weight for 0 mm stroke2720 g
- alternative connectionsSee product drawing
- Pneumatic connectionG1/8
- Material coverDie-cast aluminium Coated
- Material sealsNBR TPE-U(PU)
- Material housingAnodised
