Display- Display Type: 18.5″ TFT Color
Color: 16M Colors
Resolution: 1366 x 768
- System
- Processor Number: Intel® Core-i5 8365UE
CPU Speed: 1.6GHz@4.1GHz(4C/8T)
Memory: DDR4 SO-DIMM 8GB
Storage: 2.5″ SSD 256GB
- Serial COM1, COM2
- RS-232C, RS-422/485 Asynchronous(Selected BIOS)
Data bit: 7/8 bits, Stop bit: 1/2 bits, Parity bit: None/Odd/Even
Baud rate: 2400~115.2kbps
Connector: DSUB 9pin x 1, 3.5mm 5P x 1
- Serial COM3, COM4
- RS-232C Asynchronous
Data bit: 7/8 bits, Stop bit: 1/2 bits, Parity bit: None/Odd/Even
Baud rate: 2400~115.2kbps
Connector: DSUB 9pin x 2
- Ethernet
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.ab, 10BaseT/100BaseT/1000BaseT
Connector: RJ-45 x 2
- USB Host
- USB 2.0 Compatible, Output 5Vdc/0.5A
Connector: USB Type Micro B x 1
USB 3.1 Compatible, Output 5Vdc/0.9A
Connector: USB Type A x 4
- HDMI Out
- HDMI v1.4, HDMI output, Max. Resolution: 4096 x 2160 at 24Hz
Connector: HDMI x 1
- DP Out
- DP v1.2, HDMI output, Max. Resolution: 4096 x 2306@60Hz
Connector: DP x 1
- Audio
- High Definition Audio(HD), Line-in, Line-out, Mic-in
- Structure
- Panel Cut: 479 x 298
Dimension: 497 x 316 x 94.8
Weight: 5.6kg
Case: Metal
