| Acting type | Double acting |
|---|---|
| Tube I.D. (mm) | 10, 16, 20, 25, 32, 40 |
| Stroke | 20~160 mm |
| Medium | Air |
| Operating pressure range | 0.2~0.6 MPa |
| Ambient temperature | －5~＋60℃ (No freezing) |
| Lubrication | Not required |
| Repeatability | ±0.1mm |
| Sensor switch | RT/RDF/RDFV/RNF/RNFV/RPF/RPFV |
| Remark | ※ Maintenance: Re-Lubrication after appr. 1.5 million cycles recommended. |
