Size DN50—DN600
Nominal Pressure PN10/PN16
Working Temperature -10°C~120°C
Suitable Medium Chemicals,air,water,steam,oil, acids,salts,etc
Specification:
Size
DN50-300
Nominal pressure
PN10/16
working temperature
-10°C~120°C
suitable medium
Chemicals,air,water,steam,oil,acids,salts,etc
Standards:
Design Standard
DIN3356
Face to Face
DIN3202 F1
Flange Drilling
DIN2533 PN10/16,ANSI 125/150,BS4504,JIS10K
Test Inspection
DIN3230
Materials:
Body
Cast Iron,Duction Iron
Disc
Stainless Steel,Cast Bronze
Stem
Stainless Steel,Brass
Seat Ring
Brass
