SPECIFICATIONS
Basic Specifications and Configuration
| Display and Manipulation | 2.4-inch TFT LCD touch panel |
|---|---|
| Series Structure | 1~256 ZONE |
| Temperature-only type | VARO-6ZONE · 24-pin connector |
| Combo type | Temperature 6 points + Timer 6 points · 24-pin + 16-pin |
| Dual type | Temperature: 6ZONE + 6ZONE · 24-pin + 24-pin |
| Communications | RS485 MODBUS / Wi-Fi / Ethernet |
DIMENSIONS
Dimensions by model
Unit: mm
Width (W) × Depth (D) × Height (H)
Weight: kg
72ZONE features 12 zones × 6 sections. Please inquire about the weight.
| Model / Configuration | Horizontal W |
Depth D |
Height H |
Weight : kg |
|---|---|---|---|---|
| 1 ZONE | 110 | 260 | 210 | 4 |
| 2 ZONE | 140 | 330 | 220 | 8 |
| 4 ZONE | 300 | 340 | 220 | 18 |
| 6 ZONE | 350 | 340 | 220 | 19 |
| 8 ZONE | 450 | 340 | 220 | 27 |
| 12 ZONE | 350 | 340 | 430 | 34 |
| 18 ZONE | 340 | 390 | 990 | 49 |
| 24 ZONE | 440 | 490 | 1030 | 60 |
| 32 ZONE | 440 | 490 | 1250 | 70 |
| 36 ZONE | 490 | 490 | 1250 | 75 |
| 72 ZONE (12×6-speed) | 640 | 640 | 1850 |
