Main functions and benefits
BV-500P is a conformal coating valve designed to provide uniform spraying with an improved internal airflow structure. Engineered to handle quick-curing conformal coating fluids, the BV-500P features a nozzle placement inside the valve to ensure consistent dispensing shape for precise, clean coating applications. The valve is also designed for easy cleaning, particularly after curing, making it ideal for high-efficiency, high-precision conformal coating tasks.
Key Features
- Improved Airflow Structure: Designed to optimize internal airflow, ensuring uniform spray patterns and efficient fluid control.
- Quick-Curing Fluid Compatibility: Suitable for quick-curing conformal coating fluids, with a nozzle positioned inside the valve for consistent fluid dispensing.
- Micrometer Control: Equipped with a micrometer adjustment for precise spray control, allowing users to fine-tune the spray output.
- Easy to Clean: The internal design allows for easy cleaning of the nozzle, especially after curing, reducing downtime and improving maintenance efficiency.
Product specifications
| Model | BV-500P |
| ON/OFF Method | Needle Off |
| Applicable viscosity | 1~1,000cps |
| Input Air Pressure | 5kgf/cm2 |
| Max. fluid IN-LET pressure | 10kgf/cm2 |
| Max. operation number | 240times/min |
| IN-LET Fittings | PT 1/8″ |
| Wet-part material | SUS 303 |
| Valve material | SUS 303 |
| Weight | 400g |
| Control | Double-Action |
| Stroke Control | Micrometer |
