GENERAL
- Differencial Pressure Decay Leak Measurements : Vacuum to 20 Bar
- Multi-test leak tester
- 128 programs
- Fully integrated electronics and pneumatics
- Data storage on internal memory or USB key
-
TEST MODES
- ∆P (Pa, 1/10 Pa)
- ∆P/t (Pa/s, 1/10 Pa/s)
- Flow units (sccm, mm3/s, cm3/s, cm3/min, cm3/h…)
- Blockage test, Burst Test, Sealed Components…
- And other depending on your application
-
ENVIRONMENT
- ROHS Standard
-
FLEXIBLE COMMUNICATION FORMAT
- RS232: Printer, Modbus RTU
- Slave USB: USB key ti transfer data (parameters, results…)
- Master USB: USB key to transfer (parameters, results, …)
- Barcode Reader
| PRESSURE DROP MEASUREMENT |
|---|
| Range | Accuracy up to* | Max. Resolution |
|---|---|---|
| 0 – 50 Pa | ± (1.5% Reading + 0.5 Pa) | 0.01 Pa |
| 0 – 500 Pa | ± (1.0% Reading + 1 Pa) | 0.1 Pa |
| 0 – 5000 Pa | ± (1% Reading + 10 Pa) | 1 Pa |
Accuracy: Linearity + Repeatability + Hysteresis *Optional Laboratory Accuracy
F28+ Demo interface
F28+ Demo interface
SPECIFICATIONS
-
PHYSICAL
- Weight: 3.5 Kg
- Dimensions: (WxHxD) 157.10×298.90×13580 mm
-
ELECTRICAL SUPPLY
- 24VDC/2A or 100-240VAC/50W
-
TEMPERATURE
- Operating: + 5°C at + 45°C
- Storage: 0°C at + 60°C
