Range of product
OsiSense XC
Series name
Special format
Product or component type
Limit switch
Product specific application
For hoisting and mechanical handling applications
Device short name
XCR
Sensor design
–
Body type
Fixed
Head type
Rotary head
Material
Metal
Fixing mode
By the body
Movement of operating head
Rotary
Type of operator
Spring return rod lever metal square rod 6 mm
Type of approach
Lateral approach, 2 directions
Electrical connection
Screw-clamp terminals, clamping capacity: 1 x 0.34…2 x 1.5 mm²
Contacts type and composition
2 x (1 NC + 1 NO)
Contact operation
Snap action
Contact block per direction [control circuit]
2 per direction
Positive opening
With
