- Waterproof rating: IP67 (weatherproof enclosure)
- Operating temperature range: -20°C to +70°C
- Power supply: 110 / 220 VAC, 50/60 Hz / 24 V AC/DC options
- Indicator: Dome-type position indicator with built-in LED
- Limit switch: 2 × Open + 2 × Close (mechanical contacts, 250 VAC rated)
- Travel angle: 0° to 90° (quarter-turn)
- Manual override: Hex wrench operation (manual emergency operation)
- Cable entries:Standard PF ½” / Optional M20 × 1.5 or NPT ½”
- Heater: 2 × 3 W internal anti-condensation heater
- Case material: Aluminium alloy housing
- Lubricant: Shell Gadus S2 V220 2 grease
- Surface treatment: Anodised corrosion protection
- Standard paint finish: TGIC-free polyester powder coating
Performance Data
- Torque output: up to 60 Nm (varies by configuration)
- Rotation: 0° to 90° quarter-turn operation
- Operating time (90°): 50 Hz: ~32 seconds 60 Hz: 26 seconds
- Motor rating: approx. 25 W class motor
- Duty cycle: S2 – 15 minutes
- Supply voltage options: 24 V AC/DC 110 V AC / 220 V AC
- Current consumption (approx.): 24 V: ~ 2.1A / 110 V: ~0.35 A / 220 V: ~0.25 A
