R8 Series Servo Drive
| Product Name | Product Type | Rated Output Power | Rated Output Current | Max Output Current | Input Voltage Specification | Dimensions (mm) | Protection Level |
|---|---|---|---|---|---|---|---|
| R8-3830Z-N | EtherCAT Bus Type | 3000W | 12A | 36A | Three-phase AC 380V | 90 x 181 x 160 | IP30 |
| R8-3830P-N | Pulse Type | 3000W | 12A | 36A | Three-phase AC 380V | 90 x 181 x 160 | IP30 |
| R8-2226Z-N | EtherCAT Bus Type | 2600W | 12.0A | 36A | Single-phase/Three-phase 220VAC | 90 x 181 x 160 | IP30 |
| R8-2226P-N | Pulse Type | 2600W | 12.0A | 36A | Single-phase/Three-phase 220VAC | 90 x 181 x 160 | IP30 |
| R8-2215Z-N | EtherCAT Bus Type | 1500W | 8.4A | 25.5A | Single-phase AC 220V/Three-phase AC 220V | 57 x 199 x 182 | IP30 |
| R8-2215P-N | Pulse Type | 1500W | 8.4A | 25.5A | Single-phase AC 220V/Three-phase AC 220V | 57 x 199 x 182 | IP30 |
| R8-2210Z-N | EtherCAT Bus Type | 1000W | 6.4A | 19.5A | Single-phase AC 220V/Three-phase AC 220V | 57 x 199 x 182 | IP30 |
| R8-2210P-N | Pulse Type | 1000W | 6.4A | 19.5A | Single-phase/Three-phase 220VAC | 57 x 199 x 182 | IP30 |
| R8-2210Z-S | EtherCAT Bus Type | 1000W | 5.5A | 16.9A | Single-phase AC 220VAC | 50 x 160 x 173 | IP30 |
| R8-2210P-S | Pulse Type | 1000W | 5.5A | 16.9A | Single-phase AC 220VAC | 50 x 160 x 173 | IP30 |
| Product Name | Product Type | Rated Output Power | Rated Output Current | Max Output Current | Input Voltage Specification | Dimensions (mm) | Protection Level |
|---|---|---|---|---|---|---|---|
| R8-2208Z-B | EtherCAT Bus Type | 800W | 5.5A | 16.9A | Single-phase AC 220VAC | 50 x 160 x 173 | IP30 |
| R8-2208Z-N | EtherCAT Bus Type | 800W | 5.5A | 16.9A | Single-phase AC 220VAC | 50 x 160 x 173 | IP30 |
| R8-2208P-B | Pulse Type | 800W | 5.5A | 16.9A | Single-phase AC 220VAC | 50 x 160 x 173 | IP30 |
| R8-2208P-N | Pulse Type | 800W | 5.5A | 16.9A | Single-phase AC 220VAC | 50 x 160 x 173 | IP30 |
| R8-2204Z-B | EtherCAT Bus Type | 400W | 2.8A | 10A | Single-phase 220VAC | 50 x 160 x 173 | IP30 |
| R8-2204Z-N | EtherCAT Bus Type | 400W | 2.8A | 10A | Single-phase AC 220V/Three-phase AC 220V | 50 x 160 x 173 | IP30 |
| R8-2204P-B | Pulse Type | 400W | 2.8A | 10A | Single-phase AC 220VAC | 50 x 160 x 173 | IP30 |
| R8-2204P-N | Pulse Type | 400W | 2.8A | 10A | Single-phase 220VAC | 50 x 160 x 173 | IP30 |
