Specifications
| Sample | LR-ZB100N | |||
| Type | Distance-based laser sensor | |||
| External shape | Rectangle | |||
| Output | Anonymous | |||
| Connection Method | 2 m cable | |||
| Detectable Distance | 35 to 100 mm (650 to 0)*1 | |||
| Standard Detection Deviation | 35 to 50 mm: 1.5 mm 50 to 100 mm: 3 mm |
|||
| Display Resolution | 2 (0.2 mm) | |||
| Spot size | Approx. 2 × 1 mm at 100 mm spacing | |||
| Response Time | 1.5 ms/10 ms/50 ms selectable | |||
| Light Source | Type | Red Laser (660 nm) | ||
| Laser Type | Laser Products Type 1 (IEC60825-1, FDA (CDRH) Part1040.10*2) |
|||
| Function | Indicator light | 3-digit 7-segment display (red), output indicator (yellow), DATUM indicator (orange), 1-point indicator (blue) |
||
| Timer | OFF/Postpone ON/Postpone/Single click | |||
| Specifications | Power Voltage | 10 to 30 VDC, including ±10% ripple (P-P), Class 2, or LPS | ||
| Power Consumption | 450 mW or less (18 mA or less with 24 V, 34 mA or less with 12 V) | |||
| Control Output | NPN Open Manifold Applicable voltage of 30 VDC or less, control current of 100 mA or less, residual voltage of 1.2 V or less with 10 mA or less, 2 V or less with 10 to 100 mA |
|||
| Protection Circuit | Protection from reverse electrical connection, output overcurrent, output surge, reverse output connection | |||
| Output Operation | Selectable light ON/dark color ON | |||
| External Input | Input Time Calibration: 35 ms or more, 35 ms or more OFF Laser stop: 2 ms or more, 20 ms or more OFF NPN short-circuit current: 1 mA or less/PNP: 2 mA or less |
|||
| Environmental Resistance | Weather resistance index for enclosures | IP68 (IEC60529), IP69K (DIN40050-9), NEMA 4X, 6P, 13 (NEMA250), ECOLAB*3, Diversey*3 | ||
| Insulation | From 20 MΩ or more (500 VDC) | |||
| Ambient lighting | Round Bulb: Sunlight 4,000 lux or less: 8,000 lux or less*4 |
|||
| Ambient Temperature | -10 to +50 °C (Non-freezing) | |||
| Ambient humidity | 35 to 85 % RH (Non-condensing) | |||
| Storage Temperature | -25 to +75 °C (Non-freezing) | |||
| Voltage resistance | 1,000 VAC, 50/60 Hz, 1 minute | |||
| Vibration resistance | 10 to 55 Hz, 1.5 mm Dual amplitude in X, Y, Z directions respectively, 2 hours | |||
| Impact resistance | 1,000 m/s2, 6 times in X, Y, and Z directions | |||
| Materials | Housing: SUS316L, Display: PES, Lens cap: PMMA with scratch-resistant coating, Sealed seals/connectors: FKM |
|||
| Included accessories | User Manual, Certification/Identification Label (FDA) |
|||
| Volume | Approx. 110 g (Cables included) | |||
