Y Series – corona machine controller Kcon

Overview of corona machine features

1. The product adopts a split structure. The control system is separate from the high-voltage oil tank, so the high-voltage oil tank can be installed near the discharge rack, which greatly shortens the transmission distance of the high-voltage line and greatly avoids the safety of personnel and machinery caused by excessively long high-voltage lines.
2. Integrated drive control design. Can be installed on cabinets, making it more convenient and aesthetically pleasing.
3. The human-machine interface provides both digital tube display and touchscreen display, which can be used independently or in both modes.
4. Both the bit control and registers of RS485 are open to customers, allowing them to design their own host computer (touchscreen or PLC) according to their needs, making it easier for customers to use.
5. Extensive external ports provide convenient solutions for more functions.
1. For speed sensors, low-cost Hall sensors and high-precision encoder interfaces can be provided.
2. Independent external start and emergency stop ports.
3. Small signal OC alarm output and relay alarm output.
4. Material breakage and blockage detection with bandage.
5. Automatic power adjustment. Automatically adjusts power output according to the equipment’s discharge speed, eliminating the need for manual adjustment.
6. High-power corona machine with ground wire current detection. Even when the corona machine operates in very humid environments, it can still function normally and adaptively, without damaging the corona control system.
7. Sensitive high-voltage open-circuit, short-circuit, and overcurrent detection makes equipment operation safer.
8. Output power PID automatically adjusts to make output more stable and reduce the impact of grid voltage fluctuations. Greatly improves product consistency.
