The SA-1040 is a heavy-duty, fully automated system designed for the high-speed coiling and film wrapping of electrical cables, building wires, and flexible tubing. Engineered for seamless Extrusion Line Linkage, this machine synchronizes directly with your production line speed to provide a non-stop, “lights-out” manufacturing process.
By integrating precise length measuring, high-speed coiling, and protective film wrapping into a single station, the SA-1040 eliminates manual handling and ensures every coil is tensioned and packaged to professional retail standards. It is the ultimate solution for large-scale wire and cable factories looking to maximize throughput and minimize labor costs.
Core Product Advantages
-
Seamless Extrusion Linkage: Automatically adjusts its coiling speed to match the output of your extrusion line, preventing cable buildup or tension spikes.
-
Full-Cycle Automation: Completes the entire sequence—measuring, cutting, coiling, and film wrapping—without the need for a dedicated operator.
-
Professional Film Wrapping: Provides a tight, uniform layer of protective film, shielding the cable from dust, moisture, and abrasion during transport.
-
High-Precision Length Counting: Features a digital encoder system for micron-level accuracy, ensuring every coil meets the exact specified length.
-
Rapid Changeover Design: Easily adjust the coil inner and outer diameters via the touch-screen interface to accommodate different product specifications.
-
Industrial Durability: Built with a reinforced steel frame and high-quality components to withstand 24/7 operation in demanding factory environments.
Technical Specifications
| Specification | Details |
| Model | SA-1040 (Linkage Series) |
| Primary Functions | Auto-Coiling, Length Cutting, & Film Wrapping |
| Applicable Cable OD | 2 mm – 15 mm (Standard) |
| Coiling Speed | Up to 120 meters / minute (Line Synced) |
| Coil Inner Diameter | 120 mm – 200 mm (Adjustable) |
| Coil Outer Diameter | Max 400 mm |
| Coil Width | 30 mm – 100 mm |
| Wrapping Material | PE Film / PVC Stretch Film |
Operating Parameters
| Parameter | Performance Standard |
| Power Supply | AC 380V (3-Phase) / 220V (Optional) |
| Length Tolerance | <= 0.3% |
| Air Pressure | 0.5 – 0.7 MPa |
| Machine Weight | Approx. 650 KG |
| Control System | PLC + HMI Touch Screen (Multi-Language) |
