YZ-20 hydraulic correction Kcon

Cylinder Driver
The system uses closed-loop control, presetting the target position (correction zero point) of the strip to be monitored. During machine operation, the opposite edge detector monitors the lateral position changes of the controlled edge of the strip and converts them into electrical signals for output to the controller. The controller compares this signal with the correction zero point signal, and if there is any deviation, it outputs a corresponding deviation correction signal to the solenoid valve. The solenoid valve converts the signal into high-power hydraulic energy through the hydraulic station, driving the hydraulic cylinder to move the uncoiler accordingly until the controlled edge of the strip returns to the target position.

Product Features
+ Roll any color such as black, mirror reflective, transparent, white……. can all be easily detected and detected.
+ Any material such as paper, fabric, rubber and plastic, fine mesh, metal……. All can be detected and controlled.
+ American-made solenoid valves and control components, Japanese-made high-pressure pipes……. All parts perform well and are highly reliable.
+ Low noise, no oil leakage, high thrust, stable quality, economical and durable.
+ Tracking speed can be freely set according to operational requirements.
+ Suitable for opaque rolls, operation requires no adjustment, extremely convenient to use.
+ Can be used for special side alignment of the inner edge of the roll (generally only the outer edge correction).
Technical specifications
